Specifications

Product

Pivot Shuttle AM Pro X0 Eagle Transmission E-Bike

Model Year

2024

Riding Type

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

SM (Low, High)

MD (Low, High)

LG (Low, High)

XL (Low, High)

Size	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	599mm, 598mm	631mm, 630mm	649mm, 647mm	671mm, 670mm
Head Tube Angle	64.1°, 64.5°	64.1°, 64.5°	64.1°, 64.5°	64.1°, 64.5°
Head Tube Length	110mm	120mm	130mm	140mm
Seat Tube Angle	76.4°, 76.8°	76.4°, 76.8°	76.4°, 76.8°	76.4°, 76.8°
Seat Tube Length	378mm	399mm	432mm	470mm
Bottom Bracket Height	345mm (29mm drop), 350mm (24mm drop)	345mm (29mm drop), 350mm (24mm drop)	345mm (29mm drop), 350mm (24mm drop)	345mm (29mm drop), 350mm (24mm drop)
Chainstay Length	444mm	444mm	444mm	444mm
Wheelbase	1217mm, 1216mm	1251mm, 1250mm	1270mm, 1269mm	1295mm, 1294mm
Standover	715mm, 720mm	715mm, 720mm	715mm, 720mm	715mm, 720mm
Reach	431mm, 435mm	461mm, 465mm	476mm, 480mm	496mm, 500mm
Stack	632mm, 629mm	642mm, 638mm	651mm, 647mm	660mm, 656mm
Additional Info	• Geometry adjustable via flip chip in upper linkage. • All specifications listed are with 160mm travel fork with 44mm offset.

Wheel Size

29"

E-Bike Class

Class 1: Pedal Assist (Pedelecs)

Motor

Bosch Performance CX, 85 Nm max torque, 340% max support

Battery

Integrated, non-removable; compatible with additional Bosch PowerMore 250 Wh range extender battery

Battery Capacity

750 Wh

Display/Remote

Bosch integrated top tube Power/Mode display, Bosch wireless handlebar remote

Modes

Turbo, Sport/eMTB, Tour, Eco, Walk Assist

Max Speed with Assist

Europe: 15.5 mph (25 km/h)

Non-Europe: 20 mph (32.2 km/h)

Frame Material

Carbon Fiber

Frame Material Details

Hollow Core carbon front and rear triangles; injection molded chainstay, seatstay, and down tube protection

Rear Travel

148mm

Rear Shock

FOX FLOAT X Factory, Kashima coating, trunnion mount, 185mm length x 55mm stroke

Fork

FOX FLOAT 36 Factory E-MTB, GRIP2 damper, Kashima coating, 44mm offset

Fork Travel

160mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Pivot Precision, sealed cartridge bearings, ZS44 upper, ZS56 lower

Handlebar

Phoenix Race Low Rise Carbon
Width: 780mm (SM/MD), 800mm (LG/XL)

Stem

Phoenix Team Enduro/Trail

Grips

Phoenix Factory, lock-on

Brakes

Shimano Deore XT M8120, 4-piston, Shimano Deore XT 203mm CENTER LOCK rotors

Brake Levers

Shimano Deore XT M8120

Drivetrain

Shifters

SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless

Front Derailleur

None

Rear Derailleur

SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless

Chainguide

Upper slider

Cranks

Praxis Alloy eCranks E-MTB

Chainrings

34 tooth

Pedals

None

Chain

SRAM X0 Eagle Transmission, 12-speed

Cassette

SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth

Rims

DT Swiss Hybrid HX1501, alloy, 30mm inner width

Hubs

DT Swiss Hybrid wheelset, 15mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) with XD driver

Spokes

DT Swiss Hybrid wheelset

Tires

Front: Maxxis Minion DHF, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4” WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4” WT

Saddle

WTB Volt Pro Phoenix, medium width

Seatpost

FOX Transfer Factory dropper, Kashima coating
Drop: 150mm (SM), 175mm (MD/LG), 200mm (XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt, 36.4mm

Rear Dropout / Hub Dimensions

12mm x 157mm (SuperBoost+)

Max. Tire Size

29" x 2.5"

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube (compatible with Pivot Dock Tool System)

Colors

Blue Neptune, Mojave Willow Green

Warranty

10 years frame; 5 years Pivot/Phoenix components; 1 year paint/finish/bearings

Weight

48 lb 15.8 oz (22,220 g)

Miscellaneous

• dw-link rear suspension design
• Geometry adjustable via flip chip in upper linkage
• Compatible with mixed ("Mullet") setups (29" front, 27.5" rear) with flip chip in High position
• Compatible with 27.5+ wheels/tires
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App

Price

$11,799.00
