Specifications

Product
Pivot Shuttle AM Pro X0 Eagle Transmission E-Bike
Model Year
2024
Riding Type
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM (Low, High)
MD (Low, High)
LG (Low, High)
XL (Low, High)
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Bosch Performance CX, 85 Nm max torque, 340% max support
Battery
Integrated, non-removable; compatible with additional Bosch PowerMore 250 Wh range extender battery
Battery Capacity
750 Wh
Display/Remote
Bosch integrated top tube Power/Mode display, Bosch wireless handlebar remote
Modes
Turbo, Sport/eMTB, Tour, Eco, Walk Assist
Max Speed with Assist
Europe: 15.5 mph (25 km/h)
Non-Europe: 20 mph (32.2 km/h)
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core carbon front and rear triangles; injection molded chainstay, seatstay, and down tube protection
Rear Travel
148mm
Rear Shock
FOX FLOAT X Factory, Kashima coating, trunnion mount, 185mm length x 55mm stroke
Fork
FOX FLOAT 36 Factory E-MTB, GRIP2 damper, Kashima coating, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed cartridge bearings, ZS44 upper, ZS56 lower
Handlebar
Phoenix Race Low Rise Carbon
Width: 780mm (SM/MD), 800mm (LG/XL)
Stem
Phoenix Team Enduro/Trail
Grips
Phoenix Factory, lock-on
Brakes
Shimano Deore XT M8120, 4-piston, Shimano Deore XT 203mm CENTER LOCK rotors
Brake Levers
Shimano Deore XT M8120
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless
Chainguide
Upper slider
Cranks
Praxis Alloy eCranks E-MTB
Chainrings
34 tooth
Pedals
None
Chain
SRAM X0 Eagle Transmission, 12-speed
Cassette
SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth
Rims
DT Swiss Hybrid HX1501, alloy, 30mm inner width
Hubs
DT Swiss Hybrid wheelset, 15mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) with XD driver
Spokes
DT Swiss Hybrid wheelset
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4” WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4” WT
Saddle
WTB Volt Pro Phoenix, medium width
Seatpost
FOX Transfer Factory dropper, Kashima coating
Drop: 150mm (SM), 175mm (MD/LG), 200mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 157mm (SuperBoost+)
Max. Tire Size
29" x 2.5"
Bottle Cage Mounts
One inside front triangle, plus accessory mounts under top tube (compatible with Pivot Dock Tool System)
Colors
Blue Neptune, Mojave Willow Green
Warranty
10 years frame; 5 years Pivot/Phoenix components; 1 year paint/finish/bearings
Weight
48 lb 15.8 oz (22,220 g)
Miscellaneous
• dw-link rear suspension design
• Geometry adjustable via flip chip in upper linkage
• Compatible with mixed ("Mullet") setups (29" front, 27.5" rear) with flip chip in High position
• Compatible with 27.5+ wheels/tires
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App
Price
$11,799.00
