Specifications

Product
Mondraker Dune R E-Bike
Model Year
2025
Riding Type
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
27.5" (650b)
29"
Other: Mullet
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Bosch Performance Line SX Gen4, Smart System, 55 Nm max torque, 600 W peak power
Battery
Bosch Compact Powertube, integrated, removable
Option: Bosch Powermore range extender battery, 250 Wh
Battery Capacity
400 Wh
Display/Remote
Bosch top tube integrated System Controller and Bosch Purion 400 display, Bosch 3-button Bluetooth wireless Mini Remote
Modes
Turbo, eMTB, Tour+, Eco, Walk Assist
Max Speed with Assist
Europe: 15.5 mph (25 km/h)
Non-Europe: 20 mph (32.2 km/h)
Frame Material
Carbon Fiber
Frame Material Details
Stealth Air carbon front and rear triangles; one-piece Monoblock upper link; exclusive plastic motor covers; molded chainstay, seatstay, and down tube protection
Rear Travel
165mm
Rear Shock
FOX FLOAT X Performance, EVOL, 2-position compression lever (Open/Firm), rebound adjust, trunnion mount, 205mm length x 65mm stroke
Fork
FOX FLOAT 38 Performance, e-bike tuned, GRIP damper, 3-position compression lever with Micro Adjust, low-speed rebound adjust, 44mm offset
Fork Travel
170mm
Head Tube Diameter
Straight, 1.5"
Headset
ACROS, internal cable routing, IS52/ZS56
Handlebar
ONOFF S6 1.0, 7050 alloy, 800mm width, 25mm rise, 8° backsweep, 5° upsweep, 31.8mm clamp diameter
Stem
ONOFF S6, 6061 forged + CNC alloy, 30mm length, 0° rise, 31.8mm bar clamp
Grips
ONOFF Forest, 135mm length, single CNC lock-on
Brakes
SRAM DB8, 4-piston, steel-backed orgainc pads, SRAM CenterLine 200mm 6-bolt one-piece rotors
Brake Levers
SRAM DB8 Stealth, tooled reach adjust
Drivetrain
1x
Shifters
SRAM NX Eagle, 12-speed, Single Click
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle, 12-speed
Chainguide
Mondraker custom upper slider
Cranks
e*thirteen Helix Core e*spec Plus, 160mm length
Chainrings
SRAM Eagle, steel, X-SYNC 2, narrow/wide profile, 34 tooth, 104mm BCD
Pedals
None
Chain
SRAM NX Eagle, 12-speed, with PowerLock
Cassette
SRAM NX Eagle PG-1230, 12-speed, 11-50 tooth
Rims
e*thirteen Grappler Core, 30mm inner width, hookless 6069 welded aluminum, 28 hole, tubeless ready
Hubs
e*thirteen, fully machined aluminum, triple-sealed, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with 6°-engagement freehub and HG driver
Spokes
e*thirteen custom, J-bend, triple-butted steel, alloy nipples with washers
Tires
Front: Maxxis Assegai, 3C MaxxGrip compound, DH casing, TR, 2x 60 TPI, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, TR, 2x 120 TPI, 27.5" x 2.4" WT
Saddle
fi'zi:k Terra Aidon Slim X5
Seatpost
ONOFF Pija dropper, adjustable travel, 1x remote lever
Drop: 115-140mm (SM), 135-160mm (MD), 155-180mm (LG), 185-210mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
27.5" x 2.6"
Bottle Cage Mounts
One inside front triangle, plus Fidlock accessory mounts under top tube
Colors
Obsidian/Yellow/Gray
Warranty
Lifetime frame with registration, 3 years paint
Weight
43 lb 14.4 oz (19,913 g)
Miscellaneous
• E-Bike Optimized Zero Suspension System
• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Mondraker Forward Geometry
• HHG (Hidden Housing Guide) internal cable routing; cables route through headset
• SRAM UDH (Universal Derailleur Hanger)
• Frame weight, size MD, without shock: 5.8 lbs (2650 g)
• Includes integrated rear shock mudguard/fender
• Power settings customizable via Bosch eBike Flow Mobile App
• Compatible with optional Bosch Powermore range extender battery (250 Wh)
Price
$7,999.00
