2025 Orbea Wild H10 E-Bike

h10 green 01
h10 green 01
h10 green 02
h10 green 03
h10 tanzanite 01.jpg?VersionId=Z1dO9D4w5FHhGoFuAzI
h10 tanzanite 02
h10 tanzanite 03
h10 yellow 01.jpg?VersionId=. 9 Ybewh6uV82PeEAcUVKW
h10 yellow 02.jpg?VersionId=HykE5T
h10 yellow 03
detail 01.jpg?VersionId=Eab3aSFZF.JsNg6GcxSjLdbbAaF
detail 02.jpg?VersionId=c7VO1u4rI67Hicna
h10 green 01 h10 green 02 h10 green 03 h10 tanzanite 01.jpg?VersionId=uFqzDSm KqtJU9EaJ h10 tanzanite 02 h10 tanzanite 03 h10 yellow 01.jpg?VersionId=yjmjEFVjQlteK h10 yellow 02 h10 yellow 03 detail 01 detail 02.jpg?VersionId=1d2CclVdZMrcydav2Fixwrp7ZN
Related:
Orbea
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$4,899.00
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Orbea Wild H10 E-Bike
Model Year
2025
Riding Type
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM 29"
MD 29"
LG 29"
XL 29"
SM Mullet
MD Mullet
LG Mullet
XL Mullet
Wheel Size
27.5" (650b)
29"
Other: Mullet
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Bosch Performance Line CX, 85 Nm max torque, 250 W, 36 V
Battery
Bosch PowerTube, integrated
Options: Bosch PowerTube, 600 Wh; Bosch PowerMore range extender, 250 Wh
Battery Capacity
750 Wh
Display/Remote
Bosch BCR3100 top tube display; Bosch BRC3300 Mini remote, Bluetooth wireless
Option: Bosch Kiox 300 BHU3600 display
Modes
Turbo, Sport/eMTB, Tour, Eco, Walk Assist
Max Speed with Assist
20 mph (32.2 km/h)
Frame Material
Aluminum
Frame Material Details
AL6061 hydroformed alloy; molded down tube, chainstay, and seatstay protection; custom molded motor skid plate
Rear Travel
170mm
Rear Shock
FOX FLOAT X Performance, EVOL LV, 2-position compression lever, custom tune, trunnion mount, 205mm length x 65mm stroke
Option: FOX FLOAT X2 Factory
Fork
FOX FLOAT 38 Performance, GRIP damper, 3-position compression lever, 44mm offset
Option: FOX FLOAT 38 Factory, GRIP X2 damper
Fork Travel
170mm
Head Tube Diameter
Straight
Headset
Alloy, oxidated bearings, Orbea SIC (Sealed Internal Cables), Spin Block 124° rotation limiter
Handlebar
OC Mountain Control MC20 Alu SL, 800mm width, 20mm rise
Option: OC Mountain Control MC10 Carbon, 800mm width, 20mm or 35mm rise options
Stem
OC Mountain Control MC20, 0° rise
Option: OC Mountain Control MC11 Alu SL, 0° rise
Grips
OC, lock-on
Brakes
Shimano Deore M6120, 4-piston, Galfer rotors
Option: Shimano Deore XT M8120, 4-piston
Brake Levers
Shimano Deore M6100
Option: Shimano Deore XT M8100
Drivetrain
1x
Shifters
Shimano Deore M6100, 12-speed, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+
Chainguide
e*thirteen Plus upper slider
Cranks
e*thirteen Plus Alloy
Chainrings
e*thirteen e*spec, direct mount, 34 tooth
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Rims
OQUO Mountain Control MC32TEAM POWER
Hubs
OQUO Mountain Control MC32TEAM POWER wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
OQUO Mountain Control MC32TEAM POWER wheelset
Tires
Front: Maxxis Assegai, 3C MaxxGrip compound, EXO+ casing, TR, 2.5"
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, TR, 2.4"
Option: DH casing front/rear
Saddle
fi'zi:k Aidon, manganese rails, 145mm width, 208mm length
Seatpost
OC Mountain Control MC22 dropper, 170/200/230mm drop options, Shimano MT500 remote lever with I-SPEC EV mounting bracket
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
2.6"
Bottle Cage Mounts
One inside front triangle
Colors
Spaceship Green/Black, Bumblebee Yellow/Metallic Olive Green, Tanzanite/Blue Stone
Warranty
Lifetime frame, 3 years paint and finish
Weight

Miscellaneous
• Concentric Boost II rear suspension design
• Compatible with 29" wheels front/rear or mixed ("Mullet") wheels (29" front, 27.5" rear) via alternate linkages
• Secure Battery System (SBS)
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App
• Includes Bosch 4A battery charger (110V)
• Includes OC Computer Mount CM-05 for stem topcap
Price
$7,299.00
