Specifications

Product

Devinci Troy Frame

Riding Type

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

SM (29" Lo, 29" Hi, MX Hi)

MD (29" Lo, 29" Hi, MX Hi)

LG (29" Lo, 29" Hi, MX Hi)

XL (29" Lo, 29" Hi, MX Hi)

Size	SM (29" Lo, 29" Hi, MX Hi)	MD (29" Lo, 29" Hi, MX Hi)	LG (29" Lo, 29" Hi, MX Hi)	XL (29" Lo, 29" Hi, MX Hi)
Top Tube Length	568mm, 567mm, 568mm	594mm, 593mm, 594mm	631mm, 630mm, 631mm	656mm, 655mm, 656mm
Head Tube Angle	64°, 64.7°, 64°	64°, 64.7°, 64°	64°, 64.7°, 64°	64°, 64.7°, 64°
Head Tube Length	95mm	105mm	115mm	125mm
Seat Tube Angle	78.1°, 78.9°, 78.1°	77.8°, 78.6°, 77.8°	76.4°, 77.2°, 76.4°	76.2°, 77.0°, 76.2°
Seat Tube Length	390mm	420mm	450mm	470mm
Bottom Bracket Height	343mm, 354mm, 343mm	343mm, 354mm, 343mm	343mm, 354mm, 343mm	343mm, 354mm, 343mm
Chainstay Length	435mm, 432mm, 432mm	435mm, 432mm, 432mm	445mm, 442mm, 442mm	445mm, 442mm, 442mm
Wheelbase	1206mm, 1204mm, 1203mm	1230mm, 1228mm, 1227mm	1265mm, 1263mm, 1262mm	1289mm, 1287mm, 1286mm
Standover	737mm, 747mm, 737mm	737mm, 747mm, 737mm	737mm, 747mm, 737mm	737mm, 747mm, 737mm
Reach	440mm, 449mm, 440mm	460mm, 469mm, 460mm	480mm, 488mm, 480mm	500mm, 508mm, 500mm
Stack	613mm, 606mm, 613mm	622mm, 615mm, 622mm	631mm, 624mm, 631mm	640mm, 633mm, 640mm
Additional Info	• Geometry adjustable via two-position flip chip in lower shock mount • Mixed ("Mullet") wheels (29" front, 27.5" rear); also compatible with 29" rear wheel • All specifications listed are with 160mm travel fork with 44mm offset

Wheel Size

27.5" (650b)

29"

Other: Mullet

Frame Material

Aluminum

Frame Material Details

Aluminum Optimum G04 6061-T6 alloy, molded chainstay and down tube protection

Rear Travel

150mm

Rear Shock

RockShox Super Deluxe Select+, DebonAir spring, no-spacer trunnion mount, 185mm length x 55mm stroke

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

73mm English/BSA threaded

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

29" x 2.5" or 27.5" x 2.6"

ISCG Tabs

ISCG05

Bottle Cage Mounts

One inside front triangle

Colors

Gloss Matcha/Black

Warranty

Lifetime frame; 1 year pivots, paint, and decals

Weight

Miscellaneous

• 2025 fifth generation version
• Split Pivot rear suspension design
• Geometry adjustable via two-position flip chip in lower shock mount
• Mixed ("Mullet") wheels (29" front, 27.5" rear); also compatible with 29" rear wheel
• Shed downtube in-frame storage system
• Internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Designed for 160mm travel forks
• 28-34 tooth chainring compatibility
• 200mm post-style rear brake mounts
• Includes headset: FSA Orbit 1.5 Zero Stack, ZS44 upper, ZS56 lower
• Includes seatpost clamp: single bolt, CNC alloy, 34.9mm

Price

$2,199.00
