2025 Yeti 160E C2 E-Bike

Related:
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$4,725.00
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$6,200.00

Specifications

Product
Yeti 160E C2 E-Bike
Model Year
2025
Riding Type
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Shimano STEPS EP801
Battery
Shimano STEPS, integrated, removable
Battery Capacity
630 Wh
Display/Remote
Shimano STEPS EM800 full-color display and EM800L mode switch
Modes
Boost, Trail, Eco, Walk Assist
Max Speed with Assist
20 mph (32.2 km/h)
Frame Material
Carbon Fiber
Frame Material Details
C series carbon front and rear triangles, molded seatstay and chainstay protection
Rear Travel
160mm
Rear Shock
FOX FLOAT X Performance, trunnion mount, 205mm length x 65mm stroke
Option: FOX FLOAT X2 Factory
Fork
FOX FLOAT 38 Performance, GRIP damper, 44mm offset
Option: FOX FLOAT 38 Factory, GRIP2 damper
Fork Travel
170mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Cane Creek 40, integrated, 41mm upper, 52mm lower
Handlebar
Yeti Carbon, 800mm width, 35mm clamp diameter
Stem
Burgtec Enduro MK3, 50mm length, 35mm bar clamp
Grips
ODI Elite Pro
Brakes
SRAM Code R, 4-piston, SRAM HS2 220mm rotors
Brake Levers
SRAM Code R, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM GX Eagle, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle, 12-speed
Chainguide
OneUp custom upper slider
Cranks
Shimano
Chainrings
SRAM Eagle, direct mount, 34 tooth
Pedals
None
Chain
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth
Rims
DT Swiss H 1900 Alloy, 30mm width
Option: DT Swiss EXC 1501 Carbon
Hubs
DT Swiss H 1900 wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
DT Swiss H 1900 wheelset
Tires
Front: Maxxis Assegai, 3C MaxxTerra compound, EXO+ casing, 29" x 2.5"
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, 29" x 2.4"
Saddle
WTB Silverado Custom
Seatpost
OneUp dropper
Drop: 180mm (SM), 210mm (MD), 240mm (LG/XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.6"
Bottle Cage Mounts
One inside front triangle
Colors
Black, Turquoise, Rhino
Warranty
Lifetime frame, 1 year paint/finish
Weight
50 lb 0.2 oz (22684 g)
Miscellaneous
• Sixfinity 6-bar linkage rear suspension design
• Internally tunneled cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Compatible with coil shocks and dual-crown forks
• Power settings customizable via Shimano STEPS E-Tube Project Mobile App
• Includes Shimano STEPS E6002 battery charger

Rear suspension leverage rate adjustable via 3-position flip chip in lower shock mount:
• 25%: Most supportive, direct, and efficient
• 30%: Most balanced between composure and liveliness
• 35%: Plush and poppy with increased ramp
Price
Standard: $8,500.00
With FOX Factory suspension: $9,200.00
With DT Swiss EXC 1501 Carbon wheelset: $9,600.00
With FOX Factory suspension and DT Swiss EXC 1501 Carbon wheelset: $10,300.00
