Specifications

Product

Yeti SB160 T2 Bike

Model Year

2025

Riding Type

Enduro / All-Mountain

Freeride / Bike Park

Rider

Unisex

Sizes and Geometry

XXL

Size	SM	MD	LG	XL	XXL
Top Tube Length	571mm	602mm	624mm	651mm	670mm
Head Tube Angle	64°	64°	64°	64°	64°
Head Tube Length	95mm	101mm	107mm	118mm	140mm
Seat Tube Angle	77.5°	77.5°	77.5°	77.5°	77.5°
Seat Tube Length	365mm	400mm	440mm	470mm	485mm
Bottom Bracket Height	353mm	353mm	353mm	353mm	353mm
Chainstay Length	437mm	439mm	441mm	443mm	445mm
Wheelbase	1211mm	1246mm	1270mm	1302mm	1329mm
Standover	735mm	744mm	750mm	756mm	757mm
Reach	435mm	465mm	485mm	510mm	525mm
Stack	615mm	620mm	625mm	635mm	655mm
Additional Info	• All specifications listed are with 170mm travel fork with 588mm axle-to-crown length and 44mm offset • Bottom bracket heights are listed as "estimated" by Yeti

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

TURQ Series carbon fiber front and rear triangles; molded chainstay, seatstay, and down tube protection

Rear Travel

160mm

Rear Shock

FOX FLOAT X2 Factory, Kashima coating, 230mm length x 65mm stroke

Fork

FOX FLOAT 38 Factory, GRIP2 damper, Kashima coating, 44mm offset

Fork Travel

170mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Cane Creek 40 Integrated, 41mm upper, 52mm lower

Handlebar

Yeti Carbon, 800mm width, 35mm clamp diameter

Stem

Burgtec Enduro MK3, 50mm length, 35mm bar clamp

Grips

ODI Elite Pro

Brakes

SRAM Code RSC, 4-piston, SRAM CenterLine 200mm rotors

Brake Levers

SRAM Code RSC, tool-free reach adjust and contact point adjust

Drivetrain

Shifters

SRAM X01 Eagle, 12-speed

Front Derailleur

None

Rear Derailleur

SRAM X01 Eagle, 12-speed

ISCG Tabs

ISCG05

Chainguide

MRP AMg SL upper slider with bashguard

Cranks

SRAM X1 Eagle Carbon DUB, 170mm length

Chainrings

SRAM X1 Eagle, 30 tooth

Bottom Bracket

SRAM DUB, 73mm English/BSA threaded

Pedals

None

Chain

SRAM GX Eagle, 12-speed

Cassette

SRAM X01 Eagle XG-1295, 12-speed, 10-52 tooth

Rims

DT Swiss Custom EX 1700 wheelset, 30mm inner width
Option: DT Swiss EXC 1501 Carbon

Hubs

DT Swiss Custom EX 1700 wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) with XD driver

Spokes

DT Swiss Custom EX 1700 wheelset

Tires

Front: Maxxis Assegai, 3C MaxxTerra compound, EXO+ casing, 29" x 2.5"
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, 29" x 2.4"

Saddle

WTB Silverado Custom

Seatpost

FOX Transfer dropper
Drop: 150mm (SM), 175mm (MD), 200mm (LG-XXL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt, 36.4mm

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

29" x 2.6"

Bottle Cage Mounts

One inside front triangle

Colors

Turquoise, Raw Carbon, Mustard

Warranty

Lifetime frame and Switch Infinity Link, 1 year paint and finish

Weight

33 lb 5.4 oz (15123 g)

Miscellaneous

• Switch Infinity V2 rear suspension design
• Internally tunneled cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Frame weight: 8.39 lbs (3806 g)

Price

Standard: $7,900.00

With DT Swiss EXC 1501 Carbon wheelset: $8,900.00
