Specifications

Product
Yeti SB140 LR T3 X0 Transmission Bike
Model Year
2024
Riding Type
Trail
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
XXL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
TURQ Series carbon fiber front and rear triangles; molded chainstay, seatstay, and down tube protection
Rear Travel
140mm
Rear Shock
FOX FLOAT X Factory, Kashima coating, 210mm length x 55mm stroke
Fork
FOX FLOAT 36 Factory, GRIP2 damper, Kashima coating, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Cane Creek 40 Integrated, 41mm upper, 52mm lower
Handlebar
Yeti Carbon, 800mm width, 35mm rise, 35mm clamp diameter
Stem
Burgtec Enduro MK3, 50mm length, 35mm bar clamp
Grips
ODI Elite Pro
Brakes
SRAM Code RSC, 4-piston, SRAM CenterLine rotors (200mm front, 180mm rear)
Brake Levers
SRAM Code RSC, tool-free Reach Adjust and Contact Point Adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
ISCG05
Chainguide
None
Cranks
SRAM X0 Eagle Transmission Alloy DUB, 170mm length
Chainrings
SRAM X0 Eagle Transmission, 30 tooth
Bottom Bracket
SRAM DUB, 73mm English/BSA threaded
Pedals
None
Chain
SRAM X0 Eagle Transmission, 12-speed
Cassette
SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth
Rims
Race Face ARC Offset 30, 30mm inner width
Option: DT Swiss EXC 1501 Carbon
Hubs
DT Swiss 350, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) with XD driver
Spokes

Tires
Front: Maxxis Minion DHF, EXO casing, 29" x 2.5"
Rear: Maxxis Minion DHR II, EXO casing, 29" x 2.4"
Saddle
WTB Silverado Custom
Seatpost
FOX Transfer dropper
Drop: 150mm (SM), 175mm (MD), 200mm (LG-XXL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.6"
Bottle Cage Mounts
One inside front triangle
Colors
Turquoise, Raw Carbon, Sangria, Sage
Warranty
Lifetime frame and Switch Infinity Link, 1 year paint and finish
Weight
31 lb 2.6 oz (14134 g)
Miscellaneous
• Switch Infinity V2 rear suspension design
• Internally tunneled cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Frame weight: 7.44 lbs (3375 g)
Price
Standard: $9,000.00
With DT Swiss EXC 1501 Carbon wheelset: $10,000.00
