Specifications

Product

Yeti SB130 CLR Bike

Model Year

2022

Riding Type

Enduro / All-Mountain

Trail

Rider

Unisex

Sizes and Geometry

Size	SM	MD	LG	XL
Top Tube Length	572.1mm	603.4mm	626.7mm	655.0mm
Head Tube Angle	65.1°	65.1°	65.1°	65.1°
Head Tube Length	95.0mm	99.2mm	110.2mm	121.2mm
Seat Tube Angle	76.6°	76.6°	76.5°	76.4°
Seat Tube Length	380mm	410mm	450mm	495mm
Bottom Bracket Height	341.0mm	340.9mm	340.8mm	340.8mm
Chainstay Length	433.2mm	433.2mm	433.2mm	433.2mm
Wheelbase	1178.1mm	1209.8mm	1234.4mm	1263.9mm
Standover	729.3mm	731.5mm	733.7mm	735.8mm
Reach	425.5mm	455.6mm	475.6mm	500.6mm
Stack	614.3mm	618.3mm	628.4mm	638.5mm
Additional Info	• All specifications listed are with 160mm travel fork with 567.1mm axle-to-crown length and 44mm offset. • Bottom bracket heights are listed as "estimated" by Yeti.

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

C Series carbon fiber front and rear triangles; molded chainstay, seatstay, and down tube protection

Rear Travel

137mm

Rear Shock

FOX FLOAT X Performance, custom tune, 210mm length x 55mm stroke
Option: FOX FLOAT X Factory

Fork

FOX FLOAT 36 Performance, GRIP damper, 44mm offset
Option: FOX FLOAT 36 Factory

Fork Travel

160mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Cane Creek 40 Integrated, 41mm upper, 52mm lower

Handlebar

Race Face Aeffect R, 780mm width, 35mm clamp diameter

Stem

Race Face Ride, 50mm length, 35mm bar clamp

Grips

ODI Elite Pro

Brakes

SRAM Code R, 4-piston, SRAM CenterLine rotors (200mm front, 180mm rear)

Brake Levers

SRAM Code R

Drivetrain

Shifters

SRAM GX Eagle, 12-speed

Front Derailleur

None

Rear Derailleur

SRAM GX Eagle, 12-speed

ISCG Tabs

ISCG05

Chainguide

None

Cranks

SRAM GX Eagle DUB, 170mm length

Chainrings

SRAM GX Eagle, 30 tooth

Bottom Bracket

SRAM DUB, BB92 PressFit

Pedals

None

Chain

SRAM GX Eagle, 12-speed

Cassette

SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth

Rims

DT Swiss E1900 or E532, 30mm inner width

Hubs

DT Swiss E1900 or E532 wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) with XD driver

Spokes

DT Swiss E1900 or E532 wheelset

Tires

Front: Maxxis Assegai, EXO+ casing, 29" x 2.5"
Rear: Maxxis Minion DHR II, EXO+ casing, 29" x 2.4"

Saddle

WTB Silverado Custom

Seatpost

FOX Transfer dropper
Drop: 125mm (SM), 150mm (MD), 175mm (LG/XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt, 36.4mm

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

29" x 2.5"

Bottle Cage Mounts

One inside front triangle

Colors

Turquoise, Raw Carbon, Rhino, Watermelon

Warranty

Lifetime frame and Switch Infinity Link, 1 year paint and finish

Weight

31 lb 8 oz (14,288 g)

Miscellaneous

• Switch Infinity rear suspension design
• Internally tunneled cable routing

Price

Standard: $6,500.00

With FOX Factory suspension: $7,400.00
