Specifications

Product

Trek Top Fuel 9.9 XTR Bike

Model Year

2024

Riding Type

Cross Country

Trail

Rider

Unisex

Sizes and Geometry

SM (High, Low)

MD (High, Low)

ML (High, Low)

LG (High, Low)

XL (High, Low)

Size	SM (High, Low)	MD (High, Low)	ML (High, Low)	LG (High, Low)	XL (High, Low)
Top Tube Length	569mm, 570mm	599mm, 600mm	615mm, 616mm	631mm, 632mm	654mm, 655mm
Head Tube Angle	65.9°, 65.5°	65.9°, 65.5°	65.9°, 65.5°	65.9°, 65.6°	65.9°, 65.6°
Head Tube Length	100mm	100mm	105mm	110mm	125mm
Seat Tube Angle	75.9°, 75.5°	75.9°, 75.5°	75.9°, 75.5°	75.9°, 75.6°	75.9°, 75.6°
Seat Tube Length	395mm	420mm	435mm	450mm	500mm
Bottom Bracket Height	346mm (27mm drop), 341mm (32mm drop)	346mm (27mm drop), 341mm (33mm drop)	346mm (27mm drop), 341mm (33mm drop)	346mm (27mm drop), 341mm (33mm drop)	346mm (27mm drop), 341mm (33mm drop)
Chainstay Length	434mm, 435mm	434mm, 435mm	434mm, 435mm	434mm, 435mm	434mm, 435mm
Wheelbase	1153mm, 1154mm	1183mm, 1184mm	1200mm, 1201mm	1217mm, 1218mm	1244mm, 1244mm
Standover	724mm, 719mm	744mm, 739mm	749mm, 744mm	754mm, 749mm	764mm, 759mm
Reach	419mm, 415mm	449mm, 445mm	464mm, 460mm	479mm, 475mm	499mm, 495mm
Stack	596mm, 599mm	596mm, 599mm	600mm, 604mm	605mm, 608mm	619mm, 622mm
Additional Info	• Geometry adjustable via Mino Link flip chip in lower shock mount. All specifications listed are with 130mm travel fork with 43mm offset, for trail values of 120mm (High) and 123mm (Low) on all sizes.

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

OCLV Mountain Carbon front and rear triangles, magnesium rocker link, molded chainstay and down tube protection

Rear Travel

120mm

Rear Shock

FOX FLOAT DPS Factory, 3-position lever, Open Mode adjust, Kashima coating, 185mm length x 50mm stroke

Fork

FOX FLOAT 34 Factory, EVOL air spring, GRIP2 damper, Kashima coating, 44mm offset, Kabolt thru-axle

Fork Travel

130mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Trek Knock Block 2.0 Integrated, 72° radius rotation limiter (includes infinite-radius chip), sealed cartridge bearings

Handlebar

Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 820mm width, 27.5mm rise

Stem

Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0° rise
Virtual length: 35mm (SM), 45mm (MD-XL)

Grips

Bontrager XR Trail Elite, nylon lock-on

Brakes

Shimano XTR M9100, 2-piston, Shimano RT86 6-bolt rotors (180mm front, 160mm rear)

Brake Levers

Shimano XTR M9100

Drivetrain

Shifters

Shimano XTR M9100, 12-speed

Front Derailleur

None

Rear Derailleur

Shimano XTR M9100, 12-speed, SHADOW RD+, long cage

ISCG Tabs

ISCG05 front two bolts

Chainguide

None

Cranks

e*thirteen TRS Race Carbon, 170mm length

Chainrings

e*thirteen TRS Race, 30 tooth

Bottom Bracket

e*thirteen BB20-P, 73mm English/BSA threaded

Pedals

None

Chain

Shimano XTR M9100, 12-speed

Cassette

Shimano XTR M9101, 12-speed, 10-51 tooth

Rims

Bontrager Line Pro 30, OCLV Mountain Carbon, tubeless ready

Hubs

Bontrager Line Pro wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with Rapid Drive 108 freehub and MICRO SPLINE driver

Spokes

Bontrager Line Pro wheelset

Tires

Bontrager XR4 Team Issue, Inner Strength casing, aramid bead, 120 TPI, tubeless ready, 29" x 2.4"

Saddle

Bontrager Arvada Pro, carbon rails, 138mm width

Seatpost

Bontrager Line Elite dropper, MaxFlow
Drop: 100mm (SM), 150mm (MD/ML), 170mm (LG), 200mm (XL)

Seatpost Diameter

34.9mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

29" x 2.5"

Bottle Cage Mounts

One inside front triangle

Colors

Carbon Red Smoke, Pennyflake, Matte Emerald Iris, Matte Raw Carbon

Warranty

Lifetime frame and rims; 2 years Trek/Bontrager parts, suspension linkage components, and paint/decals

Weight

26 lb 14.3 oz (12200 g)

Miscellaneous

• ABP (Active Braking Pivot) rear suspension design
• Geometry adjustable via Mino Link flip chip in lower shock mount
• Internal frame storage compartment in down tube; includes Bontrager BITS storage bag
• Guided internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Knock Block 2.0 headset limits rotation of handlebars in event of crash
• Includes Bontrager BITS integrated steerer-tube multi-tool
• Includes Bontrager TLR tubeless rim strips, sealant, and valves
• Weight given for size MD set up tubeless

Price

$9,549.99
