Specifications

Product
Rocky Mountain Instinct C30 Shimano Bike
Model Year
2024
Riding Type
Enduro / All-Mountain
Trail
Rider
Unisex
Sizes and Geometry
XS 27.5" (Slackest, Steepest)
SM 27.5" (Slackest, Steepest)
SM 29" (Slackest, Steepest)
MD 29" (Slackest, Steepest)
LG 29" (Slackest, Steepest)
XL 29" (Slackest, Steepest)
Wheel Size
27.5" (650b)
29"
Frame Material
Carbon Fiber
Frame Material Details
SMOOTHWALL carbon front and rear triangles; molded chainstay, seatstay, lower down tube, and shuttle guard protection
Rear Travel
140mm
Rear Shock
FOX FLOAT DPS Performance, size-specific tune, 190mm length x 45mm stroke (XS/SM) or 210mm length x 52.5mm stroke (MD-XL)
Fork
Marzocchi Bomber Z2, EVOL, RAIL damper, 34mm stanchions, 44mm offset
Fork Travel
150mm
Head Tube Diameter

Headset
FSA Orbit No.85 Reach Adjust, sealed stainless steel bearings, 0mm cups installed, +/-5mm cups included
Handlebar
Rocky Mountain AM, 780mm width, 25mm rise, 9° backsweep, 5° upsweep, 31.8mm clamp diameter
Stem
Rocky Mountain AM, 40mm length, 5° rise, 31.8mm bar clamp
Grips
Rocky Mountain Light, lock-on
Brakes
Shimano MT4120, 4-piston, resin pads, Shimano rotors
Brake Levers
Shimano MT4100
Drivetrain
1x
Shifters
Shimano Deore M6100, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano Deore M6100, 12-speed
ISCG Tabs
2-bolt ISCG05
Chainguide
OneUp upper slider
Cranks
Shimano Deore, 24mm spindle
Length: 165mm (XS/SM), 170mm (MD-XL)
Chainrings
Shimano Deore, 32 tooth
Bottom Bracket
Shimano MT500, 92mm press-fit
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Rims
WTB ST Light i30 TCS 2.0, 28 hole, tubeless ready (tape and valves included)
Hubs
Shimano TC500, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
Stainless steel 2.0
Tires
Maxxis Dissector, EXO casing, TR, 2.4" WT
Saddle
WTB Volt Race, 142mm width
Seatpost
X-Fusion Manic Composite dropper
Drop: 125mm (XS), 150mm (SM), 170mm (MD/LG), 200mm (XL)
Seatpost Diameter
30.9mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
One inside front triangle
Colors
Smokin' In The Boys Room / Bad To The Bone
Warranty
5 years frame; 1 year paint, decals, and frame hardware
Weight
32 lb 1.9 oz (14,570 g)
Miscellaneous
• SMOOTHLINK Four-Bar Horst-Link rear suspension design
• 27.5" wheels available in sizes XS/SM
• 29" wheels available in sizes SM/MD/LG/XL
• Geometry adjustable via RIDE-4 flip chip at rear shock mount
• Chainstay length adjustable via two-setting flip chip at rear dropout
• Reach adjustable (+/-5mm) via modular headset cups (included)
• Fully enclosed internal cable routing
• PenaltyBox 2.0 down tube internal frame storage; includes custom tool wrap
• SRAM UDH (Universal Derailleur Hanger)
