Specifications

Product
Pivot Switchblade Pro X01 Bike
Model Year
2023
Riding Type
Enduro / All-Mountain
Trail
Rider
Unisex
Sizes and Geometry
XS (Low, High)
SM (Low, High)
MD (Low, High)
LG (Low, High)
XL (Low, High)
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core carbon fiber front and rear triangles, size-specific carbon layups; molded down tube, seatstay, and chainstay protection
Rear Travel
142mm
Rear Shock
FOX FLOAT X Factory, Kashima coating, trunnion mount, 185mm length x 55mm stroke
Fork
FOX FLOAT 36 Factory, GRIP2 damper, Kashima coating, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed cartridge bearings
Handlebar
XS-LG: Phoenix Team Low Rise Carbon, 760mm (XS) or 780mm (SM-LG) width
XL: OneUp Low Rise Carbon, 800mm width
Stem
Phoenix Team Enduro/Trail
Grips
Phoenix Factory, lock-on
Brakes
SRAM Code RSC, 4-piston, SRAM CenterLine CENTER LOCK rotors (200mm front, 180mm rear)
Brake Levers
SRAM Code RSC, reach and contact point adjustment
Drivetrain
1x
Shifters
SRAM X01 Eagle, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM X01 Eagle, 12-speed
ISCG Tabs
ISCG05
Chainguide
None
Cranks
SRAM X01 Eagle DUB
Chainrings
SRAM X01 Eagle, 32 tooth
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth
Rims
DT Swiss XM1700, 30mm width
Option: DT Swiss XMC1501 Carbon, 30mm width
Hubs
DT Swiss 350, 15mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) rear with 36 tooth Star Ratchet freehub and XD driver
Option (with XMC1501 rims): DT Swiss 240 with EXP freehub
Spokes
DT Swiss wheelset
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4" WT
Saddle
XS/SM: WTB High Tail Trail Pro Phoenix
MD-XL: WTB Volt Pro Phoenix, medium width
Seatpost
FOX Transfer Factory dropper, Kashima coating
Drop: 125mm (XS), 150mm (SM), 175mm (MD), 200mm (LG/XL)
Seatpost Diameter
30.9mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
12mm x 157mm (SuperBoost+)
Max. Tire Size
29" x 2.6" or 27.5" x 2.8"
Bottle Cage Mounts
One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System
Colors
Bass Boat Blue, Electric Lime
Warranty
10 years frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings
Weight

Miscellaneous
• dw-link rear suspension design
• Geometry adjustable via flip chip in upper linkage
• Compatible with 27.5+ wheels or mixed ("Mullet") setups (29" front, 27.5" rear)
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights start at 5.7lbs
Price
With DT Swiss XM1700/350 alloy wheelset: $6,999.00
With DT Swiss XMC1501/240 carbon wheelset: $7,999.00
