Specifications

Product
Orbea Oiz M10 Bike
Model Year
2025
Riding Type
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
OMR (Orbea Monocoque Race) carbon front and rear triangles, FiberLink upper linkage, molded chainstay protection
Rear Travel
120mm
Rear Shock
FOX FLOAT SL Factory, EVOL, OC Squidlock MP11 3-position remote lockout, Kashima coating, custom tune, 190mm lengh x 45mm stroke
Fork
FOX FLOAT 34 Step-Cast (SC) Factory, FIT4 damper, OC Squidlock MP11 3-position remote lockout, Kashima coating, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Straight
Headset
Orbea SIC (Sealed Internal Cables); Spin Block rotation limiter, oxidated bearings
Handlebar
OC Mountain Performance MP10 Carbon, 760mm width
Option: OC MC10 CB SL, 800mm width, 20mm rise
Stem
OC Mountain Performance MP21, 6° drop
Option: OC MC11, 0° rise, 40mm or 50mm length options
Grips
OC, lock-on
Brakes
Shimano Deore XT M8100, 2-piston, Shimano rotors
Brake Levers
Shimano Deore XT M8100
Drivetrain
1x
Shifters
Shimano Deore XT M8100, 12-speed, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+
ISCG Tabs
None
Chainguide
None
Cranks
Shimano Deore XT M8120
Option: 4iiii Powermeter Pod 300
Chainrings
Shimano Deore XT M8120, 32 tooth
Bottom Bracket
English/BSA threaded
Pedals
None
Chain
Shimano SLX M7100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Rims
OQUO Mountain Performance MP30Team Carbon, hookless, 30mm inner width
Hubs
OQUO Mountain Performance MP30Team wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
OQUO Mountain Performance MP30Team wheelset
Tires
Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4"
Option: Schwalbe Wicked Will, EVO line, Addix SpeedGrip compound, TLE, 29" x 2.4"
Saddle
fi'zi:k Vento Argo X5, aluminum rails
Option: Selle Italia SLR Boost SuperFlow
Seatpost
OC Mountain Control MC22 dropper, 125/150/170mm drop options; remote lever integrated with OC Squidlock MP11 suspension lever
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
Two inside front triangle
Colors
Ivory White/Bumblebee Yellow, Seaweed Carbon View/Spaceship Green, Diamond Carbon View
Warranty
Lifetime frame, 3 years paint and finish
Weight

Miscellaneous
• Advanced Dynamics UFO flexstay single pivot rear suspension design
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• Frame weight: 1950g
Price
$5,999.00
