Specifications

Product
Orbea Oiz M20 Bike
Model Year
2023
Riding Type
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
OMR (Orbea Monocoque Race) carbon front and rear triangles, FiberLink upper linkage, molded chainstay protection
Rear Travel
120mm
Rear Shock
FOX FLOAT DPS Performance, EVOL, OC Squidlock MP20 remote lockout, custom tune, 190mm lengh x 45mm stroke
Fork
FOX FLOAT 34 Step-Cast (SC) Performance, GRIP damper, OC Squidlock MP20 remote lockout, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Straight
Headset
Orbea SIC (Sealed Internal Cables); Spin Block rotation limiter
Handlebar
OC MP30 Mountain Performance, 760mm width
Option: OC MC20 Alu SL, 800mm width, 20mm rise
Stem
OC MP21 Mountain Performance, 6° drop
Length: 60mm (SM), 75mm (MD/LG), 90mm (XL)
Option: OC MC20, 0° rise, 40mm or 50mm length options
Grips

Brakes
Shimano Deore M6100, 2-piston
Option: Shimano Deore XT M8100, 2-piston
Brake Levers
Shimano Deore M6100
Option: Shimano Deore XT M8100
Drivetrain
1x
Shifters
SRAM GX Eagle, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle, 12-speed
ISCG Tabs
None
Chainguide
None
Cranks
SRAM GX Eagle DUB
Length: 170mm (SM), 175mm (MD-XL)
Chainrings
SRAM GX Eagle, 32 tooth
Bottom Bracket
SRAM DUB, English/BSA threaded
Pedals
None
Chain
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth
Rims
OQUO Mountain Performance MP28Pro
Hubs
OQUO Mountain Performance MP28Pro wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver
Spokes
OQUO Mountain Performance MP28Pro wheelset
Tires
Front: Maxxis Forekaster, Dual compound, EXO casing, TR, 120 TPI, 29" x 2.35"
Rear: Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.35"
Front option: Maxxis Dissector, 29" x 2.4"
Saddle
fi'zi:k Taiga, S-Alloy rails
Option: Selle Italia SLR Boost SuperFlow
Seatpost
OC Mountain Control MC20 dropper; remote lever integrated with OC Squidlock MP20 suspension lever; 125mm, 150mm, or 170mm drop options
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
Two inside front triangle
Colors
Powder Black/Black, Halo Silver/Blue Carbon View, Chameleon Goblin Green/Black
Warranty
Lifetime frame, 2 years paint and finish
Weight

Miscellaneous
• Advanced Dynamics UFO flexstay single pivot rear suspension design
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• Frame weight: 1950g
Price
$4,999.00
