2023 Mondraker Summum R MX Bike

al r 01.jpg?VersionId=PzUvrcMPemRdiNj43kgH
al r 01
al r 02.jpg?VersionId=KFFqoU1J39xIQ2EZjWcND9veNdBN4D4
al r 03
al r 01.jpg?VersionId=PzUvrcMPemRdiNj43kgH al r 02.jpg?VersionId=d1YsmR.GNlmXG al r 03
Related:
Mondraker
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Mondraker Summum R MX Bike
Model Year
2023
Riding Type
Downhill
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
27.5" (650b)
29"
Other: Mullet
Frame Material
Aluminum
Frame Material Details
Stealth Evo hydroformed 6061 alloy, alloy upper link, molded chainstay protection
Rear Travel
200mm
Rear Shock
FOX DHX2 Performance Elite, low-speed compression adjust, low-speed rebound adjust, spring preload, trunnion mount, 225mm x 70mm
Spring rates: 400lbs (SM), 450lbs (MD), 500lbs (LG/XL)
Fork
FOX FLOAT 40 Performance, GRIP damper, EVOL, low-speed compression adjust, low-speed rebound adjust, 56mm offset
Fork Travel
203mm
Head Tube Diameter
Straight, 56mm
Headset
ONOFF Mercurium 1.5 ZS, ACB sealed bearings
Optional: Geometry Kit: +/-1° and +/-2° cups
Handlebar
ONOFF Sulfur 1.0, double-butted 6061 alloy, 800mm width, 20mm rise, 9° backsweep, 5° upsweep, 31.8mm clamp diameter
Stem
ONOFF Krypton DH, 6061 alloy, CNC Integrated FG, 25-30mm adjustable length, 31.8mm bar clamp
Grips
ONOFF Desert, 135mm length, single lock-on
Brakes
SRAM Code R, 4-piston, steel-backed sintered metal pads, SRAM CenterLine 6-bolt one-piece rotors (220mm front, 203mm rear)
Brake Levers
SRAM Code R, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM GX DH, 7-speed, X-ACTUATION
Front Derailleur
None
Rear Derailleur
SRAM GX DH, 7-speed, X-ACTUATION, medium cage
ISCG Tabs
ISCG05
Chainguide
e*thirteen Vario compact upper slider, alloy backplate; lower pulley guide; direct mount bashguard
Cranks
Truvativ Descendant DH DUB, 165mm length
Chainrings
Truvativ Descendant DH, X-SYNC, direct mount, 34 tooth, steel
Bottom Bracket
SRAM DUB, sealed bearings, 83mm English/BSA threaded
Pedals
None
Chain
SRAM PC-1110, 11-speed, with PowerLock
Cassette
SRAM PG-720, 7-speed, 11-25 tooth
Rims
e*thirteen LG1 Plus DH, 30mm internal width, 6069 welded hookless aluminum, tubeless ready, 32 hole
Hubs
e*thirteen, fully-machined aluminum, triple-sealed, 20mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) rear with 6° engagement and HG driver
Spokes
e*thirteen Hive, triple-butted steel, alloy nipples with washers
Tires
Michelin DH34, Magi-X DH compound, double-reinforced DH shield casing, wire bead, tubeless ready, 2.4"
Saddle
SDG I-Fly 2.0 I-Beam, high-density PU foam, Cordura sides
Seatpost
SDG Micro I-Beam SP-751 Alloy, micro-adjustment, 300mm length
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 157mm (SuperBoost+)
Max. Tire Size

Bottle Cage Mounts
None
Colors
Gloss Deep Purple/Light Blue
Warranty
Lifetime frame with registration, 3 years rear triangle and paint
Weight
39 lb 7.4 oz (17,900 g)
Miscellaneous
• Zero Suspension System
• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Mondraker Forward Geometry
• HHG (Hidden Housing Guide) internal cable routing
• Compatible with 29" wheels front/rear
• Available with Geometry Kit: +/-1° and +/-2° headset cups
• UK price: 5499 GBP
• Photos show 29" version
Price
$7,799.00
