Specifications

Product

Marin Rift Zone 26" Bike

Model Year

2025

Riding Type

Trail

Rider

Kids

Sizes and Geometry

One Size

Size	One Size
Top Tube Length	515.17mm
Head Tube Angle	65.5°
Head Tube Length	95mm
Seat Tube Angle	76°
Seat Tube Length	315mm
Bottom Bracket Height	308.5mm (10mm drop)
Chainstay Length	425mm
Wheelbase	1089mm
Standover	614mm
Reach	380mm
Stack	537.57mm
Additional Info	All specifications listed are with 130mm travel fork with 42mm offset

Wheel Size

26"

Frame Material

Aluminum

Frame Material Details

Series 3 6061 aluminum, molded chainstay protection

Rear Travel

130mm

Rear Shock

X-Fusion O2 Pro R, air spring, custom tune, 190mm length x 45mm stroke

Fork

X-Fusion Velvet RLC, air spring, compression adjust, rebound adjust, 42mm offset

Fork Travel

130mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

FSA No.57E, semi-sealed cartridge bearings

Handlebar

Marin Mini-Riser, 6061 double-butted aluminum, 720mm width, 15mm rise, 4° upsweep, 9° backsweep

Stem

Marin, 3D-forged alloy, 35mm

Grips

Marin dual density

Brakes

Tektro HD-M280, 2-piston, CENTER LOCK rotors (180mm front, 160mm rear)

Brake Levers

Tektro HD-M280

Drivetrain

Shifters

Shimano Deore M5100, 11-speed

Front Derailleur

None

Rear Derailleur

Shimano Deore M5100, 11-speed, SGS cage

ISCG Tabs

ISCG05

Chainguide

None

Cranks

Marin forged alloy, 170mm length

Chainrings

Marin steel, 32 tooth, narrow/wide profile

Bottom Bracket

External, sealed cartridge bearings, 73mm English/BSA threaded

Pedals

None

Chain

KMC X-11, 11-speed

Cassette

SunRace, 11-speed, 11-51 tooth

Rims

Marin, double wall aluminum, 27mm inner width, pinned joint, 32 hole

Hubs

Front: Shimano TC500, 15mm x 100mm
Rear: forged alloy, quad sealed bearings, 141mm

Spokes

14g stainless steel

Tires

VEE Tire Co. Flow Snap, Tackee compound, wire bead, 26" x 2.4"

Saddle

Marin Speed Concept

Seatpost

Marin alloy

Seatpost Diameter

30.9mm

Seatpost Clamp

Quick release

Rear Dropout / Hub Dimensions

141mm

Max. Tire Size

Bottle Cage Mounts

One inside front triangle

Colors

Teal/Black

Warranty

5 years frame; 1 year components, paint and decals

Weight

Miscellaneous

• MultiTrac single pivot rear suspension design
• Internal cable routing with internal dropper seatpost routing
• Convertible to 24" wheels

Price

$1,699.00
