2022 Specialized Turbo Levo S-Works E-Bike
(discontinued)
Discontinued
| Where To Buy | |||
|---|---|---|---|
|
Free U.S. shipping on orders over $50, except bikes.
There is a $50 destination fee for bikes. |
Free U.S. shipping on orders over $50, except bikes.
There is a $50 destination fee for bikes. $6,499.99
|
|
|
S-Works Turbo Levo Frameset
$6,499.99
|
||
|
S-Works Turbo Levo SL Frameset
$4,999.99
|
||
|
S-Works Turbo Levo T-Type
$10,500.00
|
||
|
S-Works Turbo Levo SL
$0.00
|
||
|
S-Works Turbo Levo SL Carbon
$11,000.00
|
||
|
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply. |
||
|
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply. |
||
1 member reviews
S3 S Works Levo
The Good
MX setup up makes for a easier to flick bike.
Easy motor tuning with app.
Tunable suspension.
Easy motor tuning with app.
Tunable suspension.
The Bad
Rear Tire needs a thicker casing.
Brakes are great but always howling.
Brakes are great but always howling.
Overall Review:
Over all this is one of the best e-bikes I've ridden. The brose System is on par with the best of bosch with a slight nod to bosch with a more powerful feel.
Only upgrade needed is to the tire casing needs a dh casing or an insert in the rear at least. Magura breaks feel amazing but always howl no matter the bleed, or setup.
Bike feels way lighter than its weight.
Rate review:
FrostyMugKiller
4/24/2024 10:29am
Specifications
Product
Specialized Turbo Levo S-Works E-Bike
Model Year
2022
Riding Type
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
S1
S2
S3
S4
S5
S6
Wheel Size
27.5" (650b)
29"
Other: Mullet
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Specialized Turbo Full Power System 2.2, 565 watts of power and 90 Nm of peak torque
Battery
Specialized Turbo Technology M3-700, integrated, SBC-B22
Battery Capacity
700 Wh
Display/Remote
MasterMind Turbo Control Unit (TCU), 10-LED state of charge, 3-LED ride mode display, ANT+/Bluetooth, with handlebar remote
Modes
Eco/Trail/Turbo or MicroTune with 10%-increment support levels
Max Speed with Assist
20 mph (32 km/h)
Frame Material
Carbon Fiber
Frame Material Details
FACT 11m full carbon, sidearm chassis, full internal cable routing, molded chainstay protection and motor rock guard
Rear Travel
150mm
Rear Shock
FOX FLOAT X2 Factory, LSC, LSR, 2-position lever, Kashima, 210x55mm, Rx Tune valving
Fork
FOX FLOAT 38 Factory 29, GRIP2 damper, Boost, 44mm offset, HSC, LSC, HSR, LSR, Kashima
Fork Travel
160mm (150mm on the smallest, S1 size)
Head Tube Diameter
Tapered geo adjust head tube
Headset
Geometry adjustable headset cups
Included SWAT CC steerer tube integrated tool with chain tool and link
Included SWAT CC steerer tube integrated tool with chain tool and link
Stem
DEITY Copperhead, 35mm clamp
Grips
DEITY Knuckleduster, Black
Brakes
Magura MT7, 203mm rotors
Brake Levers
Magura MT7, custom Loic lever blade
Drivetrain
1x
Shifters
SRAM Eagle AXS, rocker paddle remote
Front Derailleur
N/A
Rear Derailleur
SRAM XX1 Eagle AXS
Chainguide
Upper guide
Cranks
Praxis Carbon M30, custom offset, 160mm
Chainrings
SRAM X-Sync Eagle, 104 BCD, 32 tooth, steel
Pedals
N/A
Chain
SRAM XX1 Eagle, 12-speed
Cassette
SRAM XG-1299 Eagle, 10-52 tooth, 12-speed
Rims
Front wheel: Roval Traverse SL 29
Rear wheel: Roval Traverse SL 27.5
Rear wheel: Roval Traverse SL 27.5
Hubs
Front wheel: Roval Traverse SL 29
Rear wheel: Roval Traverse SL 27.5
Rear wheel: Roval Traverse SL 27.5
Spokes
Front wheel: Roval Traverse SL 29
Rear wheel: Roval Traverse SL 27.5
Rear wheel: Roval Traverse SL 27.5
Tires
Front: Specialized Butcher, GRID TRAIL casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.6"
Rear: Specialized Eliminator, GRID TRAIL casing, GRIPTON T7 compound, 2Bliss Ready, 27.5x2.6"
Rear: Specialized Eliminator, GRID TRAIL casing, GRIPTON T7 compound, 2Bliss Ready, 27.5x2.6"
Saddle
Specialized Bridge, 155/143mm, Hollow Ti-rails
Seatpost
RockShox Reverb AXS with 1x remote
Travel on size S1:100mm, S2: 125mm, S3: 150mm, S4-S6: 170mm
Travel on size S1:100mm, S2: 125mm, S3: 150mm, S4-S6: 170mm
Seatpost Diameter
34.9mm
Seatpost Clamp
Alloy, 38.6mm, single bolt
Rear Dropout / Hub Dimensions
12x148mm Boost
Max. Tire Size
2.6"
Bottle Cage Mounts
Yes
Colors
Metallic White Silver / Chrome / Dream Silver
Blue Ghost Gravity Fade / Black / Light Silver
Blue Ghost Gravity Fade / Black / Light Silver
Warranty
Lifetime frame and Roval wheels, 2 years Specialized components, 2 years/15,000km for batteries and motors
Weight
N/A
Miscellaneous
The 3rd Generation Levo
Designed around “Mullet” mixed-wheel sizing, 29” front with 27.5” rear
6 geometry settings: Slack/Middle/Steep headtube angles (via adjustable headset cup) and High/Low bottom bracket heights (via a flip-chip on the Horst pivot)
Redundant seals at the Charging Port and new hatch boosts weather resistance
Fully sealed cartridge bearings
New custom-tuned motor for optimal power and torque
Updated belt ensures long-term reliable power delivery
Supports up to five hours of trail time
Integrated MasterMind Turbo Control Unit (TCU) integrates with the Mission Control phone app for advanced tuning, on-trail diagnostics, and more
MasterMind TCU out-of-the-box features:
Over-the-air updates you can do yourself
Displays remaining charge as an easy-to-read percentage
MicroTune feature allows on-the-fly adjustment of peak power and support levels in 10% increments
Personalization of display arrangement (4 choices) and 30 possible data values
Clock
“Live Consumption” teaches you how to pedal efficiently by displaying real-time miles (or kilometers) per watt-hour
Rider Power Value display feature allows you to see the power you’re putting into the bike
Heart rate pairing capability to take your training to the next level
Precision elevation tracking
MasterMind TCU out-of-the-box features:
Price
$15,000.00
