2022 Pivot Shuttle SL Pro X01 E-Bike

(discontinued)

Discontinued

s1600 photo 939743.jpg?VersionId=dMH1bez1i2vctA9HRXIzZdMD7eBQRKB

c70 photo 918419.jpg?VersionId=AWbsKSuZAYkco NvQy8avtr

c70 photo 688820.jpg?VersionId=jF Bqe1pZGDz1LKWkkeKO9UCn4CAtme

c70 photo 849932.jpg?VersionId=RAih8W7eJ8mqbItsWO6N9nHZ

c70 photo 118975.jpg?VersionId=PZofzkdKpMVG3G18FG3Wn6E

c70 photo 189929.jpg?VersionId=t xwLYihFShTiYTDn

c70 photo 720788.jpg?VersionId=99eL5LCy6sMAxNIiTxUWvjIx9r9X e

s1600 photo 118975.jpg?VersionId=FXDH8W7Szi2Py3WUhdXLEMOlPv01

s1600 photo 720788.jpg?VersionId=sFQ vrsZTeN1xYfGKlIuQ8pIWTRJwp

Pivot


Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply.	Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply. $10,999.00	Buy
Pivot Shuttle SL Pro X01 E-Bike	Pivot Shuttle SL Pro X01 E-Bike $10,999.00	Buy
Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply.	Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply. $10,999.00	Buy
Pivot Cycles \| Pivot Shuttle Sl Pro Xo Eagle Transmission Bike \| Desert Sage Green \| M	Pivot Cycles \| Pivot Shuttle Sl Pro Xo Eagle Transmission Bike \| Desert Sage Green \| M $10,999.00	Buy

Specifications

Product

Pivot Shuttle SL Pro X01 E-Bike

Model Year

2022

Riding Type

Trail

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

SM (Low, High)

MD (Low, High)

LG (Low, High)

XL (Low, High)

Size	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	598mm, 597mm	632mm, 631mm	646mm, 645mm	660mm, 659mm
Head Tube Angle	65.0°, 65.5°	65.0°, 65.5°	65.0°, 65.5°	65.0°, 65.4°
Head Tube Length	95mm	112mm	117mm	130mm
Seat Tube Angle	76.0°, 76.5°	76.0°, 76.5°	76.0°, 76.5°	76.8°, 77.2°
Seat Tube Length	368mm	394mm	432mm	470mm
Bottom Bracket Height	347mm (27mm drop), 352mm (21.4mm drop)	347mm (27mm drop), 352mm (21.3mm drop)	347mm (27mm drop), 352mm (21.2mm drop)	347mm (27mm drop), 352mm (21.2mm drop)
Chainstay Length	432mm, 430mm	432mm, 430mm	434mm, 432mm	438mm, 436mm
Wheelbase	1186mm, 1185mm	1223mm, 1222mm	1240mm, 1239mm	1272mm, 1271mm
Standover	665mm, 674mm	668mm, 677mm	674mm, 682mm	678mm, 687mm
Reach	435mm, 439mm	465mm, 469mm	475mm, 482mm	500mm, 504mm
Stack	610mm, 607mm	626mm, 622mm	630mm, 626mm	642mm, 638mm
Additional Info	Geometry adjustable via flip chip in upper linkage

Wheel Size

29"

E-Bike Class

Class 1: Pedal Assist (Pedelecs)

Motor

FAZUA RIDE 60, 43V, 60 Nm max torque, 250 W continuous power, 450 W max power

Battery

Integrated, non-removable unless motor is removed; second 210 Wh range extender battery available

Battery Capacity

430 Wh

Display/Remote

FAZUA LED Hub top tube display with USB-C port; FAZUA Ring Control remote; Bluetooth and ANT+ connectivity

Modes

Breeze, River, Rocket; plus Boost function and Walk Assist

Max Speed with Assist

20 mph (32 km/h)

Frame Material

Carbon Fiber

Frame Material Details

Hollow Core carbon front and rear triangles; molded chainstay, seatstay, and down tube protection

Rear Travel

132mm

Rear Shock

FOX FLOAT X Factory, Kashima coating, trunnion mount, 185mm x 55mm

Fork

FOX FLOAT 36 Factory E-MTB, GRIP2 damper, Kashima coating, 44mm offset

Fork Travel

150mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Pivot Precision, sealed cartridge bearings, ZS44 upper, ZS56 lower

Handlebar

Phoenix Team Low Rise Carbon, 780mm width

Stem

Phoenix Team Enduro/Trail

Grips

Phoenix Factory, lock-on

Brakes

Shimano Deore XT M8120, 4-piston, Galfer rotors (203mm front, 180mm rear)

Brake Levers

Shimano Deore XT M8120

Drivetrain

Shifters

SRAM X01 Eagle, 12-speed

Front Derailleur

None

Rear Derailleur

SRAM X01 Eagle, 12-speed

Chainguide

Upper slider

Cranks

ROTOR eKAPIC E-MTB

Chainrings

ROTOR eKAPIC E-MTB, 34 tooth

Pedals

None

Chain

KMC X12, 12-speed

Cassette

SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth

Rims

DT Swiss XM1700, 30mm inner width

Hubs

DT Swiss 350, 15x110mm Boost front, 12x157mm SuperBoost rear with 36 tooth Star Ratchet freehub and XD driver

Spokes

Tires

Maxxis Dissector, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.4” WT

Saddle

WTB Volt Pro (for Pivot/Phoenix), medium width

Seatpost

FOX Transfer Factory dropper, Kashima coating
Drop: 150mm (SM), 175mm (MD/LG), 200mm (XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt, 36.4mm

Rear Dropout / Hub Dimensions

12x157mm SuperBoost

Max. Tire Size

29" x 2.4"

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube

Colors

Desert Sage Green, Blue Denim

Warranty

10 years frame; 5 years Pivot/Phoenix components; 1 year paint/finish

Weight

N/A

Miscellaneous

• dw-link rear suspension design
• Geometry adjustable via flip chip in upper linkage
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via FAZUA Mobile App
• Weights start at 36.25 lbs (under 17kg) for Team WC build
• European price: 10499 EUR

Price

$9,999.00
