Specifications

Product
Trek Top Fuel 5 Bike
Model Year
2023
Riding Type
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
SM (high, low)
MD (high, low)
ML (high, low)
LG (high, low)
XL (high, low)
XXL (high, low)
Wheel Size
29"
Frame Material
Aluminum
Frame Material Details
Alpha Platinum Aluminum, magnesium rocker link, molded chainstay and lower down tube protection
Rear Travel
120mm
Rear Shock
X-Fusion Pro 2, 2-position damper, 185mm x 50mm
Fork
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, 42mm offset, Maxle Stealth thru-axle
Fork Travel
120mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Trek Knock Block 2.0 Integrated, 72° radius rotation limiter (includes infinite radius chip), sealed cartridge bearings
Handlebar
Bontrager Rhythm Comp, alloy, 750mm width, 15mm rise, 31.8mm clamp diameter
Stem
Bontrager Rhythm Comp, 50mm length, 0° rise, 31.8mm bar clamp, Knock Block compatible
Grips
Bontrager XR Trail Comp, nylon lock-on
Brakes
Shimano MT200, 2-piston, Shimano RT26 6-bolt rotors (180mm front, 160mm rear)
Brake Levers
Shimano MT200
Drivetrain
1x
Shifters
Shimano Deore M6100, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano Deore M6100, 12-speed, long cage
ISCG Tabs
ISCG05
Chainguide
None
Cranks
Shimano MT512
Length: 170mm (SM-LG), 175mm (XL/XXL)
Chainrings
Shimano MT512, 30 tooth
Bottom Bracket
Shimano MT501 or BB52, 73mm English/BSA threaded
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Rims
Alexrims MD35, 32 hole, 35mm width, tubeless compatible
Hubs
Bontrager alloy, 110x15mm Boost front, 148x12mm Boost rear with sealed bearings and MICRO SPLINE driver
Spokes

Tires
Bontrager XR4 Team Issue, Inner Strength sidewalls, aramid bead, 120 TPI, tubeless ready, 29" x 2.4"
Saddle
Bontrager Arvada, steel rails, 138mm width
Seatpost
TranzX JD-YSI-22PLQ dropper
Drop: 100mm (SM), 150mm (MD/ML), 170mm (LG-XXL)
Seatpost Diameter
34.9mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
29" x 2.5"
Bottle Cage Mounts
One inside front triangle
Colors
Lithium Grey, Radioactive Red
Warranty
Lifetime frame and wheels; 2 years Trek/Bontrager parts, suspension linkage components, and paint/decals
Weight
34 lb 3.5 oz (15,520 g)
Miscellaneous
• ABP (Active Braking Pivot) rear suspension design
• Geometry adjustable via Mino Link flip chip in lower shock mount
• Control Freak internal cable routing
• Internal frame storage via down tube opening
• Includes Bontrager BITS Internal Frame Storage Bag
• Knock Block 2.0 headset limits rotation of handlebars in event of crash
• Includes Bontrager TLR tubeless rim strips, valve stems, and sealant
• Weight given for size MD set up tubeless
Price
$2,699.99
