Specifications

Product

Trek Roscoe 7 Bike

Model Year

2023

Riding Type

Cross Country

Trail

Rider

Unisex

Sizes and Geometry

Size	XS	SM	MD	ML	LG	XL
Top Tube Length	552mm	586mm	614mm	630mm	646mm	677mm
Head Tube Angle	65°	65°	65°	65°	65°	65°
Head Tube Length	90mm	90mm	100mm	105mm	110mm	135mm
Seat Tube Angle	73.1°	73.1°	73.1°	73.1°	73.1°	73.1°
Seat Tube Length	340mm	360mm	420mm	435mm	450mm	500mm
Bottom Bracket Height	318.5mm (45mm drop)	321.5mm (61mm drop)	321.5mm (61mm drop)	321.5mm (61mm drop)	321.5mm (61mm drop)	321.5mm (61mm drop)
Chainstay Length	430mm	430mm	430mm	430mm	430mm	430mm
Wheelbase	1120mm	1151mm	1181mm	1198mm	1215mm	1250mm
Standover	729mm	741mm	748mm	742mm	755mm	765mm
Reach	390mm	415mm	440mm	455mm	470mm	495mm
Stack	591mm	626mm	635mm	639mm	644mm	666mm
Additional Info	XS has 27.5" wheels; SM-XL have 29" wheels

Wheel Size

27.5" (650b)

29"

Frame Material

Aluminum

Frame Material Details

Alpha Gold Aluminum, molded chainstay and lower down tube protection

Rear Travel

Hardtail

Rear Shock

None

Fork

RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, Maxle Stealth thru-axle
Offset: 37mm (XS), 42mm (SM-XL)

Fork Travel

140mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

FSA IS-2

Handlebar

XS/SM: Bontrager alloy, 750mm width, 15mm rise, 31.8mm clamp diameter
MD-XL: Bontrager Rhythm Comp, alloy, 780mm width, 15mm rise, 31.8mm clamp diameter

Stem

Bontrager alloy, 7° rise, 31.8mm bar clamp, Blendr compatible
Length: 35mm (XS-SM), 50mm (MD-XL)

Grips

Bontrager XR Trail Comp, nylon lock-on

Brakes

Shimano MT200, 2-piston, Shimano RT10 180mm CENTER LOCK rotors

Brake Levers

Shimano MT200

Drivetrain

Shifters

Shimano Deore M6100, 12-speed

Front Derailleur

None

Rear Derailleur

Shimano Deore M6100, 12-speed, long cage

ISCG Tabs

ISCG05

Chainguide

None

Cranks

Shimano MT511
Length: 170mm (XS-LG), 175mm (XL)

Chainrings

Shimano MT511, 30 tooth, steel

Bottom Bracket

Shimano BB52, 73mm English/BSA threaded

Pedals

VP-536 nylon platform

Chain

Shimano Deore M6100, 12-speed

Cassette

Shimano Deore M6100, 12-speed, 10-51 tooth

Rims

Bontrager Line Comp 30, 28 hole, tubeless ready

Hubs

Shimano, MT400 110x15mm Boost front, MT510 148x12mm Boost rear with MICRO SPLINE driver

Spokes

Bontrager wheelset

Tires

Bontrager XR4 Team Issue, Inner Strength sidewalls, aramid bead, 120 TPI, tubeless ready, 2.6"

Saddle

Bontrager Arvada, steel rails, 138mm width

Seatpost

TranzX JD-YSP18 dropper
Drop: 100mm (XS/SM), 130mm (MD), 150mm (ML-XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

148x12mm Boost

Max. Tire Size

2.6"

Bottle Cage Mounts

Two inside front triangle

Colors

Matte Trek Black, Teal/Trek Black, Miami Green/Trek Black

Warranty

Lifetime frame and wheels; 2 years Trek/Bontrager parts and paint/decals

Weight

30 lb 13.5 oz (13,990 g)

Miscellaneous

• XS has 27.5" wheels; SM-XL have 29" wheels
• Guided internal cable routing
• Includes Bontrager TLR tubeless rim strips, tire sealant, and valves
• Weight given for size MD
