Specifications

Product

Marin Rift Zone 29 3 Bike

Model Year

2022

Riding Type

Trail

Rider

Unisex

Sizes and Geometry

Size	SM	MD	LG	XL
Top Tube Length	580.24mm	606.36mm	632.50mm	658.60mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	100mm	105mm	110mm	115mm
Seat Tube Angle	76°	76°	76°	76°
Seat Tube Length	390mm	400mm	425mm	430mm
Bottom Bracket Height	344mm (34mm drop)	344mm (34mm drop)	344mm (34mm drop)	344mm (34mm drop)
Chainstay Length	425mm	425mm	425mm	425mm
Wheelbase	1158.92mm	1186.00mm	1213.00mm	1240.10mm
Standover	691.84mm	697.10mm	717.83mm	721.97mm
Reach	430mm	455mm	480mm	505mm
Stack	602.60mm	607.15mm	611.70mm	616.25mm

Wheel Size

29"

Frame Material

Aluminum

Frame Material Details

Series 3 6061 aluminum; molded chainstay protection

Rear Travel

125mm

Rear Shock

FOX FLOAT DPS Performance, EVOL, 3-position compression adjust, rebound adjust, custom tune, 210mm x 50mm

Fork

Marzocchi Bomber Z2, RAIL damper, Sweep Adjust, 44mm offset, Kabolt axle

Fork Travel

130mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

FSA No.57E, semi-sealed cartridge bearings

Handlebar

Marin Mini-Riser, 6061 double-butted aluminum, 780mm width, 28mm rise, 5° upsweep, 9° backsweep

Stem

Marin 3D forged alloy, 35mm length

Grips

Marin, single clamp lock-on

Brakes

Shimano MT420, 4-piston, 203mm front rotor, 180mm rear rotor

Brake Levers

Shimano MT4100, I-SPEC EV clamps

Drivetrain

Shifters

Shimano SLX M7100, 12-speed

Front Derailleur

None

Rear Derailleur

Shimano SLX M7100, 12-speed, SGS cage, direct attachment

ISCG Tabs

ISCG05

Chainguide

None

Cranks

FSA GRID, modular 1x, MegoEXO spindle
Length: 170mm (SM), 175mm (MD/LG/XL)

Chainrings

FSA GRID, 32 tooth, direct mount, MegaTooth Technology

Bottom Bracket

FSA MegoEXO, 73mm English/BSA threaded

Pedals

None

Chain

KMC X-12, 12-speed

Cassette

SunRace, 12-speed, 11-51 tooth

Rims

Marin, double wall aluminum, 29mm inner width, sleeved joint, tubeless compatible, 32 hole

Hubs

Forged alloy, 110x15mm Boost front, 148x12mm Boost rear with quad sealed bearings and HG driver

Spokes

14g stainless steel

Tires

VEE Tire Co. Flow Snap, Tackee compound, 72 TPI, tubeless compatible, 29" x 2.35"

Saddle

Marin Speed Concept

Seatpost

X-Fusion Manic dropper, 1x composite remote lever
Drop: 125mm (SM), 150mm (MD/LG), 175mm (XL)

Seatpost Diameter

30.9mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

148x12mm Boost

Max. Tire Size

Bottle Cage Mounts

One inside front triangle

Colors

Gloss Black/Roarange/Red

Warranty

5 years frame; 1 year components, paint and decals

Weight

Miscellaneous

• MultiTrac single pivot rear suspension design
• Internal cable routing

Price

$2,999.00

More Info

marinbikes.com
