Specifications

Product

Pivot Shuttle AM Ride E-Bike

Model Year

2022

Riding Type

Trail

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

Size	SM	MD	LG	XL
Top Tube Length	600mm	620mm	640mm	667mm
Head Tube Angle	64.3°	64.3°	64.3°	64.3°
Head Tube Length	110mm	120mm	130mm	140mm
Seat Tube Angle	74°	74°	74°	74°
Seat Tube Length	395mm	424mm	458mm	496mm
Bottom Bracket Height	358mm	358mm	358mm	358mm
Chainstay Length	441mm	441mm	441mm	441mm
Wheelbase	1187mm	1214mm	1235mm	1264mm
Standover	715.0mm	715.0mm	722.6mm	722.6mm
Reach	420mm	440mm	460mm	485mm
Stack	614mm	624mm	633mm	642mm

Wheel Size

29"

E-Bike Class

Class 1: Pedal Assist (Pedelecs)

Motor

Shimano STEPS EP8

Battery

Integrated, removable via two bolts

Battery Capacity

726 Wh

Display/Remote

Shimano STEPS

Modes

Boost, Trail, Eco, Walk Assist

Max Speed with Assist

20 mph (32 km/h)

Frame Material

Carbon Fiber

Frame Material Details

Carbon front and rear triangles; molded chainstay, seatstay, and down tube protection

Rear Travel

140mm

Rear Shock

FOX FLOAT X Performance, 200mm x 50.8mm

Fork

FOX FLOAT 36 Performance E-MTB, GRIP damper, 44mm offset

Fork Travel

160mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Pivot Precision, sealed cartridge bearings, ZS44 upper, ZS56 lower

Handlebar

Phoenix Race Low Rise Aluminum

Stem

Phoenix Team Enduro/Trail

Grips

Phoenix Factory, lock-on

Brakes

Shimano SLX M7120, 4-piston, Galfer rotors (203mm front, 180mm rear)

Brake Levers

Shimano SLX M7120

Drivetrain

Shifters

Shimano SLX M7100, 12-speed, I-SPEC EV bracket

Front Derailleur

None

Rear Derailleur

Shimano Deore XT M8100, 12-speed, SGS cage

Chainguide

Upper slider

Cranks

Shimano EM600 E-MTB

Chainrings

Shimano E-MTB, 34 tooth

Pedals

None

Chain

Shimano Deore M6100, 12-speed

Cassette

Shimano Deore M6100, 12-speed, 10-51 tooth

Rims

DT Swiss EB 1935 wheelset, 30mm width

Hubs

DT Swiss EB 1935 wheelset, 15x110mm Boost front, 12x157mm SuperBoost rear with MICRO SPLINE driver

Spokes

DT Swiss EB 1935 wheelset

Tires

Front: Maxxis Assegai, 3C compound, EXO+ casing, TR, 29" x 2.5”
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 29" x 2.4”

Saddle

Pivot Pro E-Bike

Seatpost

KS Rage-i dropper
Drop: 125mm (SM), 150mm (MD/LG), 170mm (XL)

Seatpost Diameter

30.9mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

12x157mm SuperBoost

Max. Tire Size

29" x 2.5" or 27.5" x 3.0"

Bottle Cage Mounts

None

Colors

Blue Mirage

Warranty

10 years frame; 5 years Pivot/Phoenix components; 1 year paint/finish

Weight

N/A

Miscellaneous

• dw-link rear suspension design
• Compatible with 27.5+ wheels
• Internal cable routing
• Compatible with 635 Wh and 508 Wh batteries
• Power button and charging port integrated with Pivot Cable Port System

Price

$9,599.00
